4 ft. T-LED Lamps

$8.29$8.57

The PLG Linear LED Lamp System

PLG offers a wide variety of LED solutions to replace traditional linear fluorescent light sources. Products are UL and DLC listed*, and can be compatible with existing ballast, wired directly to line voltage, or installed with a separate LED driver.

Please contact our sales team directly for information and ordering of custom product configurations.

SKU: N/A Categories: ,

Description

Features:

  • High Power Factor > .90
  • Low Total Harmonic Distortion < 25%
  • High Efficacy, up to 150 lumens per watt
  • High CRI > 80
  • Long Life 50,000+ hours / 5 year warranty
  • Wide beam angles available, up to 312 degrees
  • Unified Glare Rating (UGR) < 19
  • No UV or IR radiation
  • Ballast compatibility list can be provided upon request
  • Ballast bypass, direct line voltage input available in single sided or double sided input
  • UL listed*
  • DLC Listed*

*All size, materials, and performance combinations may not be listed. Please reference listing agency to verify, or ask your PLG representative. Any combination not currently listed can be listed upon request.

Additional information

Weight 8.96 oz
Dimensions 48 × 1.2 × 1.2 in
T-LED Material

AL (Aluminum), GL (Glass), NA (Nanoplastic)

T-LED UL Type

A (Ballast Compatible), A/B (Dual Mode), B (Direct Line Voltage), C (External LED Driver)

CCT

2700K, 3000K, 3500K, 4000K, 5000K

Wattage

8W, 9W, 10W, 12W, 15W, 18W, 22W, 30W, 40W

PLG T8 Series TLED Spec Sheet

Download

5 Year Limited Warranty TLED Series

Download

T8 Photometric Data File (IES)

Download

T8 Photometric Data File Notes (IES)

Download
